VRB Series Planetary Gearbox Reducer Nidec For Stepper Motors And Servo Motors

Name: VRB Series Planetary Gearbox Reducer Nidec For Stepper Motors And Servo Motors
Brand: Nidec
Price: 1 USD

Brand Name : Nidec

Model Number : VRB

Certification : CE,ISO

Place of Origin : Japan

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 100,000 pcs per month

Delivery Time : Negotiation

Packaging Details : Standard export carton packing, wooden case, foam board inside for protection.

Product Name : Nidec Shimpo Gearbox

Manufacturer : Nidec Shimpo

Product Series : VRB Series

Model : VRB 180

Weight : 10KG

Gearing Type : Helical Planetary

Mounting : Motor Mount Kit

Reducer Input : Coupling, Bushing

Application : Dental machine, cnc machinetextile equipment, etc.

Contact Now

Product Description:

A valuable alternative for applications requiring high positional accuracy and dynamic performance. The VRB is a <3 arc-min gearbox that offers a through hole mounting design, making it easier to assemble onto various equipment. This product is an ideal fit for various belt drive and actuator applications found throughout the packaging and assembly cell automation markets.

Various standard wash down and food grade options are available, making the VRB an attractive choice for the toughest environments. We offer the broadest selection of frame sizes and ratios, with immediate availability on most configurations. Industry standard mounting dimensions allow the VRB to be employed in legacy equipment designs, saving our customers time and money.

Technical Parameters:

Frame size	Stage	Ratio	Nominal output torque	Maximum output torque	Emergency stop torque	Nominal input speed	Maximum input speed	Permitted radial load	Permitted axial load
Frame size	Stage	Ratio	[Nm]	[Nm]	[Nm]	[rpm]	[rpm]	[N]	[N]
180	1 Single	3	500	970	2200	1500	3000	5600	4300
		4	750	1400	2750	1500	3000	6200	4900
		5	750	1400	2750	1500	3000	6700	5400
		6	750	1400	2750	1500	3000	7100	5800
		7	750	1400	2750	1500	3000	7400	6300
		8	750	1400	2750	1500	3000	7800	6600
		9	500	970	2200	1500	3000	8100	7000
		10	500	970	2200	1500	3000	8400	7300
	Double	15	500	970	2200	1500	3000	9600	8700
		16	750	1400	2750	1500	3000	9800	8900
		20	750	1400	2750	1500	3000	11000	9900
		25	750	1400	2750	1500	3000	11000	11000
		28	750	1400	2750	1500	3000	12000	11000
		30	500	970	2200	1500	3000	12000	12000
		35	750	1400	2750	1500	3000	13000	13000
		40	750	1400	2750	1500	3000	13000	13000
		45	500	970	2200	1500	3000	14000	14000
		50	750	1400	2750	1500	3000	14000	14000
		60	750	1400	2750	1500	3000	15000	14000
		70	750	1400	2750	1500	3000	15000	14000
		80	750	1400	2750	1500	3000	15000	14000
		90	500	970	2200	1500	3000	15000	14000
		100	500	970	2200	1500	3000	15000	14000

Frame size	Stage	Ratio	Maximum radial load	Maximum axial load	Weight	Moment of inertia (≦φ19)	Moment of inertia (≦φ28)	Moment of inertia (≦φ38)	Moment of inertia (≦φ48)
Frame size	Stage	Ratio	[N]	[N]	[kg]	[kgcm2]	[kgcm2]	[kgcm2]	[kgcm2]
180	1 Single	3	15000	14000	36	-	44	66	130
		4	15000	14000		-	28	50	110
		5	15000	14000		-	22	44	100
		6	15000	14000		-	18	41	100
		7	15000	14000		-	16	38	99
		8	15000	14000		-	15	37	97
		9	15000	14000		-	14	36	97
		10	15000	14000		-	14	36	96
	2 Double	15	15000	14000	37	4.7	12	34	-
		16	15000	14000		5.4	13	35	-
		20	15000	14000		4.4	12	34	-
		25	15000	14000		4.2	12	34	-
		28	15000	14000		4.9	13	35	-
		30	15000	14000		3.2	11	33	-
		35	15000	14000		4.0	12	34	-
		40	15000	14000		3.1	11	33	-
		45	15000	14000		4.0	12	34	-
		50	15000	14000		3.1	11	33	-
		60	15000	14000		3.1	11	33	-
		70	15000	14000		3.1	11	33	-
		80	15000	14000		3.1	11	33	-
		90	15000	14000		3.1	11	33	-
		100	15000	14000		3.1	11	33	-

VRB Series Planetary Gearbox Reducer Nidec For Stepper Motors And Servo Motors

Advantages:

1. Complete range: Straight Teeth Gearbox and Helical Gearbox.

2. Straight Teeth Gearboxes are more efficient and Helical Gearboxes have a longer service life.

3. Compliant with ISO 9001:2015 quality standards and ISO 14001 environmental standards.

4. We have a comprehensive shipping and after-sales service to ensure the quality of our products.

5. If you need a large number of purchases, you can contact us to obtain preferential prices.
